Indoor Transparent Film LED Display
GLK1000Tif series indoor LED transparent film screen, mainly used for building glass curtain walls, has the characteristics of high transparency and ultra-thin. The film’s transparent screen and the glass curtain wall can be said to hit it off, and the Goldluckled film screen adds a special aesthetic feeling to urban buildings.
High Transparency
The transparency of the transparent film display can reach 90%. The screen is invisible when not playing, and does not affect the indoor lighting. When viewed from a distance, there is no trace of the screen installation.
Ultra-thin and Ultra-light
Film LED display wall thickness is about 5mm, weight 6kg/m², lightweight, no pressure on the glass
High Flexibility
Film LED displays can be bent and cut, not limited by size, and can be flexibly designed according to customer needs.
High Quality
LED film screen, a new generation of high-tech transparent screen product, has a high brightness of 5000cd/m², a high contrast ratio of 2000:1, and a high resolution of 3840HZ. It is worth your choice.
Easy to Install
LED film transparent screen is easy to install, just stick to the glass surface directly.
Wide Viewing Angle
The viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle gives you the largest screen viewing area.
Extensive Application Scenarios
LED film transparent display can be applied in glass curtain walls, glass guardrails, glass windows shop windows, etc., and has obvious technical advantages.
| Pixel Pitch (mm) | P4-8 | P6.5 | P5-10 | P8 | P10 | P16 | P20 |
|---|---|---|---|---|---|---|---|
| Model | GLK-iFilm-P4-8 | GLK-iFilm-P6.5 | GLK-iFilm-P5-10 | GLK-iFilm-P8 | GLK-iFilm-P10 | GLK-iFilm-P16 | GLK-iFilm-P20 |
| Pixel Configuration | SMD2121 with driver | SMD2121 with driver | SMD2121 with driver | SMD2121 with driver | SMD2121 with driver | SMD2121 with driver | SMD2121 with driver |
| Density (Pixels/㎡) | 32,250 | 23,718 | 20,000 | 15,625 | 10,000 | 7,812 | 5,000 |
| Module Resolution (Pixel) | 240×8 | 148×8 | 192×8 | 120×8 | 96×8 | 60×8 | 48×8 |
| Driving Mode (Duty) | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 |
| Cabinet Size (mm) | customize | customize | customize | customize | customize | customize | customize |
| Cabinet Weight (KG) | 6kg/㎡ | 6kg/㎡ | 6kg/㎡ | 6kg/㎡ | 6kg/㎡ | 6kg/㎡ | 6kg/㎡ |
| Brightness (CD/㎡) | 5500 | 5000 | 5000 | 5000 | 5000 | 3000 | 2500 |
| Transparency | 60% | 55% | 80% | 80% | 85% | 85% | 90% |
| Viewing Angle (°) | 140 | 140 | 140 | 140 | 140 | 140 | 140 |
| Gray Grade (Bits) | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
| Max. Power Consumption (W/㎡) | 800 | 800 | 700 | 700 | 700 | 400 | 300 |
| Avg. Power Consumption (W/㎡) | 200 | 200 | 150 | 150 | 150 | 120 | 100 |
| Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 | ≥60 |
| Refresh Frequency (Hz) | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Working Temperature (ºC) | -10～+65 | -10～+65 | -10～+65 | -10～+65 | -10～+65 | -10～+65 | -10～+65 |
| Lifetime (Hours) | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 |
| Protecting Grade | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 |
