GLK169F2 640×360 16:9 Indoor HD Front Service LED Display

GLK169F2 Indoor 16:9 LED Video Wall


GLK169F2 LED screen, thin design, front service, easy to install and maintain. The LED display has a wide viewing angle and provides excellent image quality, suitable for indoor commercial applications.


16:9 Lightweight Cabinet


16:9 LED display, cabinet 16:9 resolution, perfect replacement for LCD display. The die-cast aluminum cabinet ensures a smooth and seamless picture. Good uniformity.


Full Front Service


GLK169F2 Series LED display adapts full front service design, and the LED display modules, LED power supplies and the LED control cards can be replaced in front easily. The LED modules are assembled in front with magnetic features.


Advanced UHD 8K Experience


The GLK169F2 series LED display adopts a cabinet ratio of 16:9, which is flexible to install and can easily create FHD, 2K, 4K, 8K, and 16K video walls.


Wireless LED Module


LED module data and power input plug-and-play design, no need for additional DC power lines and cables, easy to install, saves trouble and effort.


Unparalleled Visual Performance


GLK169F2 indoor commercial LED display, seamless splicing, higher flatness, meets various indoor application scenarios and provides better visual effects.


Wide Viewing Angle


The viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle. Ultra-wide viewing angle gives you the largest screen viewing area. It offers you clear and natural images in all directions.


Application scenario


Indoor LED screen has a wide range of uses, they can be used in many fields such as business, entertainment, education, etc.




Shopping mall

Shopping Mall

Retail Store



Indoor Front Service LED Display EA169F2 Series Parameter

Pixel Pitch (mm) P1.25 P1.53 P1.86
Model GLK169F2-P1.25 GLK169F2-P1.53 GLK169F2-P1.86
Pixel Configuration SMD1010 SMD1010 SMD1515
Density (Pixels/㎡) 640,000 418,889 286,667
Module Resolution (Pixel) 256×144 208×116 172×96
Module Size (mm) 320×180 320×180 320×180
Driving Mode (Duty) 1/60 1/60 1/64
Cabinet Size (mm) 640×360 640×360 640×360
Cabinet Weight (KG) 4.1 4.1 4.1
Brightness (CD/㎡) 300~800 300~800 300~800
Viewing Angle (°) 140 140 140
Gray Grade (Bits) ≥14 ≥14 ≥14
Operation Power AC100-240V 50-60Hz AC100-240V 50-60Hz AC100-240V 50-60Hz
Max. Power Consumption (W/㎡) ≤ 500 ≤ 500 ≤ 500
Avg. Power Consumption (W/㎡) 100~180 100~180 100~300
Frame Frequency (Hz) ≥60 ≥60 ≥60
Refresh Frequency (Hz) ≥3,840 ≥3,840 ≥3,840
Working Temperature (ºC) -10~+60 -10~+60 -10~+60
Lifetime (Hours) 100,000 100,000 100,000
Protection Grade IP35 IP35 IP35
