Indoor Fixed Installation LED Screen (GLK-iFixed Series)
The SMD Encapsulation technology with High Refresh Rate and High Grey Grade with Reliable Driving IC.
Compare with outdoor fixed LED display, indoor fixed LED screen has a lower birghtness.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/1-4.jpg)
Uniform color, High contrast
We select the best driver ICs for indoor LEDs with high reliability,
and contrast ratio to meet the needs of a high refresh rate, high grayscale, and optimal color uniformity.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/2-4.jpg)
Delicate Cabinet Design
Indoor fixed installation LED display products are lighter in weight, LED display with quick lock function,
compact structure, and easy to install. The user-friendly handlebar design makes it easier to move the cabinet.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/3-4.jpg)
High Efficiency Cooling
The indoor fixed LED display cabinet has a good heat dissipation hole structure, and absolutely quiet operation.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/4-5.jpg)
Seamless Display, Better Visual Effects
High-precision LED displays make seamless splicing image and video display, offering you the perfect visual experience you desire.
The picture quality confronts viewers with an entirely new sensory experience.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/5-3.jpg)
Wide Viewing Angle
The viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle gives you the largest screen viewing area. It offers you clear and natural images in all directions.
![EA-iFixed LED Display](https://www.eagerled.com/wp-content/uploads/2019/10/fixed-indoor.jpg)
Pixel Pitch | P3 | P4 | P5 |
---|---|---|---|
Pixel Configuration | GLK-iFixed-P3-768×768 | GLK-iFixed-P4-512×512 | GLK-iFixed-P5-640×640 |
Pixel Configuration | SMD2121 | SMD2121 | SMD2121 |
Density (Pixels/㎡) | 111,111 | 62,500 | 40,000 |
Module Resolution (Pixel) | 64×64 | 64×32 | 64×32 |
Module Size (mm) | 192×192 | 256×128 | 320×160 |
Driving Mode (Duty) | 1/32 | 1/16 | 1/16 |
Cabinet Size (mm) | 768×768 | 512×512 | 640×640 |
Cabinet Weight (KG) | 12 | 8 | 11 |
Brightness (CD/㎡) | 700 | 800 | 700 |
Viewing Angle (°) | 140 | 140 | 140 |
Gray Grade (Bits) | 14 | 14 | 14 |
Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
Max. Power Consumption (W/㎡) | 525 | 580 | 312 |
Avg. Power Consumption (W/㎡) | 175 | 190 | 104 |
Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 |
Refresh Frequency (Hz) | 1920/3840 | 1920/3840 | 1920/3840 |
Working Temperature (ºC) | -20~+60 | -20~+60 | -20~+60 |
Lifetime (Hours) | 100,000 | 100,000 | 100,000 |
Protection Grade | IP31 | IP31 | IP31 |
